Detailed Description
The CAT 6A S/FTP Patch Cord is a high-performance networking cable that meets the stringent requirements of modern data centers and SMB applications. This cable is specifically engineered to support 10GBase-T Ethernet, ensuring exceptional bandwidth and reliable signal transmission.
Key Features:
- Shielding Type: Individual shield for each pair made of aluminum/polyethylene terephthalate (Al/PET) foil with an overall shield comprising at least 30% aluminum braiding. This dual shielding enhances signal integrity and minimizes EMI and crosstalk.
- Conductor Material: Stranded bare copper conductors for optimal conductivity and durability.
- Insulation: High-density polyethylene (HDPE) ensures robust signal transmission and mechanical stability.
- Color Coding: Standard color code scheme with insulation colors: White-Blue, White-Orange, White-Green, White-Brown.
- Outer Jacket: Made of low-smoke zero-halogen (LSZH) material, flame-retardant, and compliant with IEC 60332-1 and IEC 61034 standards.
- Termination: Gold-plated RJ45 connectors for reliable and durable connections.
This patch cord is suited for applications requiring high data rates, mechanical strength, and compliance with recognized international standards.
Specifications
-
Frequency Bandwidth
- 500 MHz
-
Data Rate Support
- 10 Gbps
-
Outer Jacket Tensile Strength
- ?13.5 MPa
-
Outer Jacket Elongation
- ?150%
-
Aging Period
- 100°C ? 24h ? 7d
-
After Aging Tensile Strength
- ?12.5 MPa
-
After Aging Elongation
- ?125%
-
Cold Bend
- No visible cracks at -20°C ± 2°C ? 4h
-
Min. Bend Radius
- 4.34 ± 0.2 cm
-
Max. DC Conductor Resistance Unbalance
- 5%
-
1-500 MHz Delay Skew
- ?45 ns/100m
-
Max. Conductor Resistance at 20°C
- 145 Ω/km
-
Compliance Standards
- ISO/IEC 11801, DIN EN 50173 Category 6A
